Output Interface/Splitter. #pedalboard #guitargear #guitarpedals
Instrument selector with volume control. #guitar #guitarpedals #pedalboard
Rehouse work. Schaller Fuzz Sustain with added voltage control. #guitar #pedalboard #fuzzpedal #fuzz
Custom Interface with Wha insert loop and amp switching functions. Made for @bluesmumrik ,check out his pedalboards that includes several Backlineverket pedals. One of them is the BT-2 power supply that was a limited build with only 5 units made. @tgt11 have one in stock and this is the last one https://tgt11.com/product.html/backlineverket-bt-2-battery-box-limited-edition?category_id=14
Rehouse work. Ibanez Soundtank CS5 Super Chorus. #pedalboard #guitar #guitarpedals
Volume pedal interface. Switchable line driver loop for long cable runs. #pedalboard #guitargear
Here is a nice board just finished using the GigRig G3 Atom Switcher. #pedalboard #guitar #gigrig @that_pedal_show
Custom switcher for @nickperri
Backlineverket Flatboards in stock @tgt11 Two different sizes 60x35cm and 45x33 cm. https://tgt11.com/brand.html/backlineverket #pedalboard #guitargear
Stereo, Wet/Dry/Wet pedalboard interface. Mono or Wet/Dry is also possible. Buffered input and sends, Individual Line Drivers for each AMP output. Transformer-coupled stereo outputs. Phase switches and ground lift. Master MUTE for all outputs. Permanently active tuner feed. 30 volt internal power supply for maximum headroom. #pedalboard #guitar #guitargear #guitarpedals #guitarpedalboard
3 channel iso-transformer unit with phase correction switches. #lundahltransformers
Pedalboard Interface. A/B input, Stereo Out, Bank Switch for GigRig G3 Atom. #pedalboard #guitargear #guitar #guitarpedal
Dual loop pedal. Toggles between two audio loops with one switch. Send and return on TRS jacks to save space. #pedalboard #guitar #guitarpedals
Rackmount pedalboard. Made for a studio workstation with angled desktop rack. The bottom shelf is hidden inside the studio desktop. Amp switcher/splitter to feed four amps. Pre and post effect DI. Switchable re-amp input and satellite pedalboard insert. Everything is midi controlled. #pedalboard #guitargear
Small satellite board for a larger system I’m currently working on. #guitar #guitargear #pedalboard
Custom DC/DC Power Supply. 12V input and 3 regulated 24V outputs. Each output is isolated and provides 50mA of current. #pedalboard #guitargear
Finished two mini pedals today. First one is a switchable volume control for a Gibson RD guitar. And the Fuzz Friend is a passive pickup simulator circuit. #guitar #guitarpedals #pedalboard
Boss pedals! #guitar #guitargear #pedalboard
Rehoused Boss CE-2 built for @bluesmumrik @tgt11
Pedalboard interface. Switchable A/B in and out. Jensen transformer. Tuner out/MUTE. #pedalboard #guitar #guitarpedals
Output interface for WET/DRY setups. Active signal splitter, dual output line driver isolated with Jensen transformer. Includes an effect loop for the WET effects that can be routed to output 2 for a two amp WET/DRY setup. Or the effect loop can be routed to output 1 for a single amp setup.
Input/Output selector. Designed for a setup with two instruments connected to a two channel amp with separate inputs. Toggles between Electric to ch-1 and Contra is muted. Or Contra to ch-2 and Electric is muted.
New day new pedal. Similar design as my previous channel/effect switchers but this one has a TRS jack instead of a fixed cable and a toggle switch to reverse the state of the vibrato LED to make it compatible with different amps.
New pedalboard interface for my friend @bluesmumrik @tgt11
Studio setup with vintage effects. #pedalboard
Here is an Electronic Load I built today for my workshop. Handy instrument for testing DC power supplies.
3x external spare loop patch bay with cable loom. Built for easy access to the loops in studio environment. Isolated high current power supply.
Remote channel/effect switching for vintage amps. This one is for a 1964 Fender Super Reverb. On these types of vintage amps the footswitch circuitry is a part of the audio path which makes the foot switch cable very sensitive for interference. This unit solves that problem by using relays for the switching. The audio path stays close to the amp and can be remote switched with long cables. This way noise and interference is kept down to a minimal. #guitar #pedalboard #fender #guitargear
Here is a big board just finished. 16 audio loops! A custom "effects order" switchbox mounted under the board makes it possible to insert the Gigrig QMX-10 in the DOD delay effects loop. So all the effects in the QMX-10 loop strip can be used either in the DOD delay loop or in front of the DOD delay. #pedalboard #guitar #guitargear
Pedalboard/Rack junction boxes
Active signal splitter to feed 5 amplifiers. Individual MUTES for each output that can be controlled from the front panel or via remote switching. All outputs are isolated with Lundahl transformers. Gain structure is identical from input to any output. Phase correction switches and integrated analog AC/DC power supply.
Custom unit for keyboard. Crossfade mixer for two stereo keyboards. It also has a mono input that can be splitted and summed to stereo input 1. Uses a 30V internal DC converter for maximum headroom.
Pickup simulator for Fuzz Face pedals and other buffer sensitive type of circuits. #guitar #guitarpedals #pedalboard #fuzzpedal #fuzzface #fuzz
Shin-ei fuzz wah rehoused for @bluesmumrik #guitar #pedalboard #guitargear
Here is a board just finished using Backlineverket Flatboard 45x33cm #pedalboard #guitargear
Happy Friday
The BT-2 is a battery power supply with built in voltmeter. Each battery has a test button that gives you the ability to measure the voltage off the 9V batteries. The output power jacks are bypassed while measuring to display the exact voltage of the batteries without load. The BT-2 automatically activates the batteries when power is applied to the DC input jack and it disconnects the batteries when power is removed to save battery life. Available for purchase at @tgt11
DC splitter. #guitar #pedalboard #guitargear #guitarpedals
Line driver with effects loop and permanently active tuner out. #pedalboard #guitarpedals #guitar
Dual A/B switcher #guitar #guitargear #pedalboard #guitarpedals
New batch of the popular 4 Cable Patchbay/Interface available for purchase at @tgt11
Input and Output selectors. Balanced and stereo in/out.
Custom Routing Interface. Line Driver, FX Loop, Switchable A/B output, Isolated Tuner Feed and MUTE. #pedalboard #guitar #guitarpedals
Buffered Input Selector #pedalboard #guitar #guitarpedals
Custom Vibrato/Reverb on/off switcher built for @teodornaess @insulanderamps
AC Power Distribution Unit
Backlineverket 4 Cable Patchbay in stock and available for purchase @tgt11 .The simplest way to switch between 2 and 4 cable method without having to rearrange your whole pedalboard.
Custom A/B switch. Tuner/Amp feed. Passive and simple. #guitar #pedalboard
Four button external switch expander for RJM mastermind GT midi controllers. #guitar #guitargear #pedalboard
Four switchable audio loops. GST-1 loop with +/- 20dB gain trim for both send and return. GST-2 loop with line mixer and independent WET/DRY control. Mixer send phase rev switch. Illuminated push button MUTE switch. Tuner output. 24VDC stabilized internal analog power supply with voltage switch for 115/230V operation. #guitar #guitargear #pedalboard
Stereo Routing Interface. Custom built for Mando Diao. Switches between Radial SGI setup or standard cable. With Lundahl isolation transformer. #guitar #guitargear #pedalboard
Custom LP-2 pedal with tuner out/mute. #guitar #pedalboard #guitargear
Back in the workshop. +/- 20dB input gain trim.
Here is the latest pedalboard I built for @dregenofficial #pedalboard #guitar #guitargear
Breadboarding day. 115VAC powered parallel mixer with wet and dry control. We be included in a bigger system I’m working on. #guitar #guitargear #pedalboard
Pedalboard for acoustic double neck guitar! #pedalboard #guitar #guitargear
Current doubling and voltage regulator. 4X “standard” 9VDC inputs converted to a high current 12VDC output.
